ARK-1220
英特爾凌動E3940 QC SoC，4K分辨率，雙HDMI /雙LAN / M.2 DIN導軌安裝無風扇嵌入式工控機
- 英特爾凌動E3940四核SoC Turbo突發(fā)頻率高達1.8 GHz
- DIN導軌系統，正面擋板上具有基本的I / O端口
- 2個Intel GbE和4個USB 3.0
- 雙HDMI顯示器最高4K分辨率
- 1個帶SIM卡座的全尺寸mPCIe和1個用于WIFI的M.2 2230
- 1個2.5英寸SATA III SSD和1個全尺寸mSATA *
- 12V?28V寬范圍電源輸入
- -30?70°C擴展工作溫度
- 研華WISE-PaaS支持
- CPU
- Frequency
- Core Number
- BIOS
- Intel Atom E3940 Quad Core Soc
- 1.6 GHz, turbo burst 1.8GHz
- 4
- AMI EFI 64 Mbit
- Technology
- Max. Capacity
- Socket
- DDR3L 1866 MHz
- 8 GB
- 2 x 204-pin SO-DIMM, 2 x 4GB or 1 x 8GB memory
- Chipset
- Graphic Engine
- HDMI
- Dual Display
- Intel HD Graphics 500, CPU integrated
- Gen9 Low Power; 18 Execution Units Media Codec Supported: H.264, MPEG2, MVC, VC-1, WMV9, H.265 / HEVC, VP8, JPEG / MJPEG, 3D HW Acceleration: OpenGL 4.4, DirectX* 12, OpenCL* 2.0
- HDMI1 : 3840 x 2160 @ 30Hz; HDMI2 : 3840 x 2160 @ 30Hz
- HDMI1 + HDMI2
- LAN1
- LAN2
- 10/100/1000 Mbps Intel i210 GbE, support Wake On Lan
- 10/100/1000 Mbps Intel I210 GbE, support Wake on LAN
- Interface
- Realtek ALC888S, High Definition Audio, Line-out, Mic-in
- Serial port
- USB
- GPIO
- 2 x RS-232/422/485 with auto flow control, COM2 with 5V/12V power supply
- 4 x USB 3.0
- 8-bit Programmable DIO (Optional)
- Mini PCIe
- M.2
- 1 x Full-size mPCIe with SIM holder
- 1 x M.2 2230 E key for WIFI module
- 2.5" HDD/SSD
- mSATA
- 1 x 2.5" SATAIII Drive bay (compatible with 15mm height)
- 1 x Full-size mSATA (*share with mPCIe slot)
- Watchdog timer
- TPM
- 255 levels timer interval, setup by software
- SLB9665XQ2.0 FW5.62 (By T-PN, MOQ 30pcs)
- Microsoft Windows
- Linux
- Windows 10 Enterprice
- Support by project
- Power Type
- Input Voltage
- Power Adaptor
- Consumption
- AT/ATX
- 12 ~ 28 VDC
- AC to DC, 60W (Optional)
- TBD
- Construction
- Mounting
- Dimensions
- Weight
- Aluminum housing
- DIN-rail/Wall Mount
- 53.5 x 158 x 114 mm (2.11" x 6.22" x 4.49")
- 0.9kg
- Operational Temperature
- Storage Temperature
- Relative Humidity
- Vibration during Operation
- Shock During Operation
- With extended temp. peripherals: -30 ~ 70 C (-22 ~ 158F) w/ turbo burst off with 0.7 m/s air flow; With 2.5 inch hard disk: 0 ~ 40 °C (32 ~ 104°F) with 0.7 m/s air flow
- -40 ~ 85° C (-40 ~ 185° F)
- 95% @ 40° C (non-condensing)
- With SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
- With SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration
- EMC
- Safety Certifications
- CE/FCC Class B, CCC, BSMI
- UL, CB, CCC, BSMI
